958 - 50,8mm SORTER BELT
Free Shipping!!
| Pitch | 50.8 mm |
| Thickness | 16 mm |
| Open Surface Ratio (%) | Flat Top |
| Module Width | 254 mm |
| Widthness | 50 mm |
| Colour | White/Gray |
| Cleanability | Average (FDA Food Grade) |
| Pin Diameter | 6 mm |
| Major Diameter | Up to the sprocket size |
|
|
| Polypropylene (PP | +1 | +110 |
| Polyacetal (POM) | -40 | +90 |
| Polyethylene (PE) | -60 | +100 |
| Belt Material | Roller Material | Pin Materaial (Ø5,65) | Belt Strength | Temperature | Weight of the Belt |
|---|---|---|---|---|---|
| Polyacetal (POM) | Polyacetal (POM) | PP | 3.528 kg/m | 1 - 93C | 17.98 kg/m2 |
| Stock Code | P | Color | Material | PIN | Kg / m | br |
|---|---|---|---|---|---|---|
| 958 B01 K01 | 50,8 | White (B) | Polypropylene | PP | 11.236 | m |
| 958 B02 K01 | 50,8 | White (B) | Polyacetal | PA | 11.236 | m |
| 958 G01 K01 | 50,8 | Gray (G) | Polypropylene | PP | 11.236 | m |
| 958 G02 K01 | 50,8 | Gray (G) | Polyacetal | PA | 11.236 | m |
Fields of Usage:
- Food Industry
- Automative Industry
- Meat Industry
- Pharmaceutical Industry
- Becerage Industry
- Fruit and Vegetable Sector
- Canned Food Industry
- Sea Products
- Confectionary Industry
- PacKaging Industry
- Corrugated Cardboard Sector
- Bakery Products
